SIZE
|
NPS 1/2 ~ NPS 36 |
DN 15 ~ DN 900 |
Temp.
|
-196℃ ~ 200℃ |
Design
|
ASME B16.34,BS6364 |
Inspection and testing
|
API 598, BS6364 |
Marking
|
MSS SP-25 |
P/T rating
|
ASME B16.34 |
Fugitive emission
|
ISO 15848 |
Face to face
|
ASME B16.10 |
End to end
|
Manufacturer std or ASME B16.10 |
Socket welding
|
ASME B16.11 |
Screwed ends
|
ASME B1.20.1 |
Flanged
|
ASME B16.5 |
Butt welding
|
ASME B16.25 |
Bonnet type
|
Side entry Top entry Integral extended bonnet |
Structure
|
Floating ball Trunnion mounted ball |
Features
|
Fire safe, Anti-static, Anti-blowout |
Body material
|
LCB/LCC, CF8, CF3, CF8M, CF3M etc. |
Seat material
|
Soft seat: PCTFE
Metal seat: STL, HVOF coating |
